ST80 Transmission Housing Assembly
Description
# |
Magic # |
OEM # |
Part Description |
# Req. |
1 | ST8 41271405-612 | 30160394-501 | Housing, lower, RH | 1 |
1A | ST8 41271405-611 | 30160394-500 | Housing, lower, LH | 1 |
2 | ST8 41271406-612 | 30160395-501 | Housing, middle, RH | 1 |
2A | ST8 41271406-611 | 30160395-500 | Housing, middle, LH | 1 |
3 | ST8 41271407-612 | 30160396-501 | Housing, upper, RH | 1 |
3A | ST8 41271407-611 | 30160396-500 | Housing, upper, LH | 1 |
4 | ST8 41286467-612 | 30175356-501 | Bumper plate, RH | 1 |
4A | ST8 41286467-611 | 30175356-500 | Bumper plate, LH | 1 |
5 | ST8 41271723 | 30160612 | Hinge pin, Trans., OEM | 1 |
5A | ST8 41271723-M | NA | Hinge pin, Trans., Magic | 1 |
6 | ST8 N475111888-R | NA | Lock, hinge pin, RH | 1 |
6A | ST8 N475111888-L | NA | Lock, hinge pin, LH | 1 |
7 | ST8 41283291 | 30172180 | Motor, Trans., ST80 | 1 |
8 | ST8 41271403-6 | NA | Gasket set, Trans., ST80 | 1 |
9 | ST8 41282542 | 30171431 | Bolt, connecting rib | 2 |
10 | ST8 62323-27 | 51212-16 | Dowell, pin | 4 |
11 | ST8 41286558-2 | 30175447-1 | Level, bubble, Trans. | 1 |
11A | NA | NA | Screw, level, size 6-32 x 3/4 | 2 |
12 | ST8 41271736 | 30160625 | Gasket, motor, Trans. | 1 |
13 | R/H039047 | NA | Key, motor, Trans. | 1 |
All manufacturers names, numbers, symbols, and descriptions are used for reference purposes only, and it is not implied that any part listed is the product of these manufacturers. All trademarks are property of their respective owners. The terms NOV and VARCO are registered trademarks owned by Varco I/P, Inc. or National Oilwell Varco, L.P., and Magic Industries is not endorsed, sponsored, or affiliated with Varco I/P, Inc. or National Oilwell Varco, L.P.
